500kg Self Loading Electric Pallet Stacker

The forklift mentioned in this manual is a semi electric self-lift stacker. It is ground transport equipment. It is suitable to transport goods with cargo. Self loading forklift load capacity: 500kg lift height: 800mm, 1m & 1.3m optional. 1. Steering Chain auxiliary device; 2. The foot brake, more stable; 3. Sealed batteries free of maintenance; safe operation and no pollution; 4. Explosion-proof valve design down more stable and reliable; 5. Over discharge protection, extending battery life.

Send Inquiry

Product Introduction

New 500kg self loading electric pallet stacker warehouse equipment can use car with 800mm, 1000mm, 1300mm lift height

self loading forklift (8)

self loading forklift (9)

Specification of 500kg electric pallet stacker

Features	1.1	Model			CDD05Z
	1.2	Power unit			Battery
	1.3	Rated capacity	Q	kg	500
	1.4	Load center	c	mm	400
	1.5	Wheel base	L0	mm	758
	1.6	Front track base	W1	mm	380
	1.7	Rear track base	W2	mm	665
	1.8	Operator type			Pedestrian/Standing

Tyres	2.1	Tyre type(Front/Rear)			Nylon
	2.2	Balance/Load wheels			2/2
	2.3	Load wheel size		mm	Φ70×60
	2.4	Balance wheel size		mm	φ100×45

Demension	3.1	Lowered Fork height	H2	mm	85
	3.2	Max.lifting height	H	mm	1200
	3.3	Max.fork width	W3	mm	535
	3.4	Fork length	L2	mm	1150
	3.5	Fork width×Fork thickness	B	mm	155×60
	3.6	Overall length	L1	mm	1570
	3.7	Total width	W	mm	786
	3.8	Overall height(Mast closed)	H1	mm	1597
	3.9	Overall height(Fork lowering)	H3	mm	1618
	4.0	Min.turning radius	Wa	mm	1100

Performance	4.1	Lifting speed		mm/s	55
	4.2	Lowering speed		mm/s	70
	4.3	Lifting motor power		kW	DC0.8
	4.4	Battery voltage		V	12
	4.5	Battery capacity		Ah	45

Weight	5.1	Battery weight		kg	13.5
Weight	5.2	Operating weight(with battery).		kg	245
