Electric Hydraulic Fork Lift Type Forklift
ELECTRIC REACH TRUCK FEATURE
Load Capacity: 1000-2000kg,
lift height: 3000mm;
Max. lifting height is 5500mm.
1.Speed Limited for high position,to aviod the possibility of products' overturning when high speed in high position;
2.Curve safe control,the forklift will reduce the speed automatic when turning, to aviod the ejection of operator and products from the vehicle by the high speed;
3.Regenerative braking function to reduce the operation cost;
4.Safe cutoff valve,to protect the operator and goods in well condition;
5.Shock Absorption of Pedal,to ensure the comfortable of working and reduce the fatigue.
Model
TFA10 -16 | TFA10 -25 | TFA10-30 | TFA10-35 | TFA15-25 | TFA15-30 | TFA20-16 | ||
Load capacity kg | 1000 | 1000 | 1000 | 1000 | 1500 | 1500 | 2000 | |
Load center mm | 500 | 500 | 500 | 500 | 500 | 500 | 500 | |
Max. lifting height mm | 1600 | 2500 | 3000 | 3500 | 2500 | 3000 | 1600 | |
Wheel type | Polyurethane solid tire | |||||||
Mast forwarding length mm | 550 | 550 | 550 | 550 | 650 | 650 | 700 | |
Fork size mm | 1070*100 | 1070*100 | 1070*120 | |||||
Overall length(with forks) mm | 2330 | 2330 | 2330 | 2330 | 2280 | 2280 | 2350 | |
Overall width mm | 1090 | 1090 | 1090 | 1090 | 1090 | 1090 | 1090 | |
Overall height mast closed mm | 2140 | 1850 | 2100 | 2350 | 1850 | 2100 | 2140 | |
Total weight( with battery) kg | ~1800 | ~1840 | ~1860 | ~1880 | ~1860 | ~1880 | ~1970 | |
