1.5-2.5 Ton Muti-Direction Reach Forklift Truck
1.5-2.5 Ton Muti-Direction Reach Forklift Truck MQ Series
Multi-direction reach truck MQ series is used in the very narrow aisle for long material handling, lift height is 3-8m, it has models of straight traveling, side traveling, oblique traveling and in situ rotating, the best choice for metal profiles, rebar, wood, steel pipe, and others.
Main Features:
1. All directions traveling, used in the very narrow aisle for long material handling;
2.Full AC system, electric power steering, long service life, and low energy consumption;
3.Imported gear pump, full buffer hydraulic cylinder, stable body, and low noise;
4.Imported controller, high precision control, easy electric control setting, high performance and low fault;
5.Imported hydraulic hose, durable and long service life;
6. Cast steel drive box, High strength PU tires, driving stable, braking reliable;
7.High definition drive wheel display;
8.Big capacity battery.
| Model | MQ1530 | MQ1545 | MQ2530 | MQ2545 | |
| Power Type | Battery | Battery | Battery | Battery | |
| Operation Type | Stand on | Stand on | Stand on | Stand on | |
| Service weight(incl. battery) | kg | 2530 | 2600 | 3700 | 3900 |
| Rated Capacity | Q(kg) | 1500 | 1500 | 2500 | 2500 |
| Load Center | C(mm) | 500 | 500 | 500 | 500 |
| Lifting height | h3(mm) | 3000 | 4500 | 3000 | 4500 |
| Forks size | l/e/s(mm) | 920/100/35 | 920/100/35 | 920/100/45 | 920/100/45 |
| Front Overhang | x(mm) | 140 | 140 | 175 | 175 |
| Turning radius | Wa(mm) | 1610 | 1610 | 1975 | 1975 |
| Max. climbing ability | %(tanθ ) | ≤8 | ≤8 | ≤10 | ≤10 |
| Driving speed(load/unload) | km/h | 7/8 | 7/8 | 7.8/9 | 7.8/9 |
| Lifting speed(load/unload) | mm/s | 120/190 | 100/190 | 220/300 | 220/300 |
| Lowering speed(load/unload) | mm/s | 190/170 | 170/130 | 310/260 | 310/260 |
FAQ:
Q1: Are you electric reach truck factory?
A1: Yes, we are the professional manufacturer of electric reach truck for more than 20 years.
Q2: How about the delivery time?
A2: About 20-30 days based on different models. For some standard products, we may have stock and could delivery immediately.
Q3: Is customized solution available?
A3: Yes, we can provide a different customized solutions.
Q4: Can you provide OEM service?
A4: Yes.
Hot Tags: 1.5-2.5 ton muti-direction reach forklift truck, China 1.5-2.5 ton muti-direction reach forklift truck manufacturers
