Small Electric Reach Truck
Product Description
PRODUCT FEATURES 1.Maintenance-freeandhighpowerACdrivesystemprovidereliabledrivingpower, 2.CURTScortrolerisreliableanddurable,pMPwatemproofanddustproofpugwhichgirvesreliableprotectiontothelineandgreatlyreduceselectricalfaults. 3.Standontype, EPSsteeringandintegratedHandlemakeworksafe,labor-saving,flexibleoperation
| Brand | NOELIFT | NOELIFT | NOELIFT | |
| Model | TFA15 (Single cylinder, single mast) (Single cylinder, duplex mast) | TFA15 (Double cylinders, duplex mast) | TFA15 (Triplex mast) | |
| Power type | Battery | Battery | Battery | |
| Operation type | Stand-on | Stand-on | Stand-on | |
| Rated capacity | Q(kg) | 1500 | 1500 | 1500 |
| Load center | C(mm) | 500 | 500 | 500 |
| Front overhang | x(mm) | 120 | 130 | 130 |
| Wheelbase | y(mm) | ≤1480 | ≤1480 | ≤1480 |
| Service weight(incl.battery) | kg | 1850 | 2100 | 2150 |
| Wheel type | PU | PU | PU | |
| Load wheel | mm | φ210×85 | φ210×85 | φ210×85 |
| Drive wheel | mm | φ230×75 | φ230×75 | φ230×75 |
| Auxiliary wheel | mm | φ150×50 | φ150×50 | φ150×50 |
| Number of wheels,front/rear(X=drive wheel) | 2/1x+2 | 2/1x+2 | 2/1x+2 | |
| Wheel tread, drive side | b10(mm) | 678 | 678 | 678 |
| Wheel tread, load side | b11(mm) | / | / | / |
| Fork tilting | α/β(°) | / | / | / |
| Mast closed height | h1(mm) | Refer to mast specification | Refer to mast specification | Refer to mast specification |
| Free lift height | h2(mm) | / | / | / |
| Lift height | h3(mm) | Refer to mast specification | Refer to mast specification | Refer to mast specification |
| Mast extended height with load-backrest | h4(mm) | Refer to mast specification | Refer to mast specification | Refer to mast specification |
| Pedal height | h7(mm) | 170 | 170 | 170 |
| Support leg height | h8(mm) | 245 | 245 | 245 |
| Overall length(pedal off/on) | L1(mm) | ≤2400* | ≤2400* | ≤2450* |
| Overall width | b1/b2(mm) | 900/≤1120* | 900/≤1120* | 900/1105 |
| Fork size | l/e/s(mm) | 1070/100/35 | 1070/100/35 | 1070/100/35 |
Packaging & Shipping
Packaging Details: International packing way, packed with thick plastic film.
Lead Time: 30 DAYS AFTER ADVANCE PAYMENT
Company Information
NOELIFT EQUIPMENT CO.,LTD, as one of the professional material handling equipment manufacturer, we provide whole product range including diesel/gasoline/LPG forklift truck with load capacities of 1 to 10tons and electric/warehouse trucks, which including 1-3.5tons electric forklift trucks, 1-2.5tons electric reach trucks, electric stackers, electric pallet trucks, hand-hydraulic pallet trucks, semi-electric stackers, electric tow tractors, etc. The full range encompassess close to 100 different models.
Considering the requirements of customers, we realize that a better price should be combined with the best service. Therefore, we will promise to provide quality products at a lower price, and provide you with 7x24 hours of online service. Let's join hands and you'll find what you want. Any agent or distributor would be very grateful.
Certifications
Our products passed ISO 9001: 2000 Quality System Certification, and got CE, GS certificate and third-party detection instituation test.
Related Products
As a professional manufacturer of forklift, we also offer you customized products,
the following items are optional:
Power source: Diesel, Gasoline, LPG, AC/DC electrical
Rated capacity: 1ton to 45ton
Mast: 2 stage/2-stage full free mast,3-stage full free mast
Please feel free to contact me, I am delighted to serve you all the day up!!
Our Services
1. One-stop solution service.
2. Customized-service all accepted.
3. Customer service is in time.
4. Warranty: 12 months.
5. Afford OEM service.
6. Accept the feedback and improve.
Any questions please do not hesitate to contact with me!
FAQ
Q: Why should i choose you?
A: Firstly, as a comprehensive forklift machinery manufacturers, we can offer you competitive price and as a fact we have dealed with numbers of client friends. furthermore, our company has equipped with a group of diligent, honest and enterprising staff. So we are sure that we can make quick response to your questions all the time. Actually, most problems can be solved within 10 hrs. lastly, we guarantee that the forklift can be delivered within 30days after advance payment.
Q: Which payment terms can we accept?
A: Normally we can work on L/C , T/T, Western Union and MoneyGram
Q: How long will our price be valid?
A: We are a tender and friendly supplier, never greedy want the profit. Basically, our price remains stable within 30 days. And we only adjust our price on the two issues, i.e. the rate of USD to RMB and the vary of production price of the forklift. Thank you.
Q: How can I get the after-sales service?
A: The global service network hasn’t been constructed, but you can contact with us if you have questions or need professional support, we will try to solve your problem in 24hrs, and arrange the delivery of the essential spare parts.
