Light weight, more suitable for small spaces and floor work
Three-pivot electric forklift Specifications
TKA three fulcrum counterweight forklift is a light forklift. Due to its small size and light weight, it is more suitable for small space and floor operation, which is suitable for horizontal handling and stacking in narrow channel.
Features of Three Fulcrum Electric Forklift
1. Maintenance free AC drive system makes the whole vehicle react more quickly and accurately.
2. Advanced Curtis controller, more stable and safer.
3. Small diameter bearing wheel, lower front suspension, safer.
4. Pure electric steering, small steering force, comfortable and energy saving.
5. The multi way valve controls the lifting and tilting of the fork with high control accuracy.
6. Standard turning speed limit and high lift speed limit.
7. Standard electric limit for maximum lifting height.
Specifiction parameters
| Model | TKA10 | |
| Power Type | Battery | |
| Operation Type | Driving style | |
| Rated Capacity | Q(kg) | 1000 |
| Load Center | C(mm) | 500 |
| Front Overhand | x(mm) | 168 |
| Wheelbase | y(mm) | 975~990~1020 |
| Service Weight(incl.battery) | kg | 1700 |
| Weight distribution when loaded,drive side/load side | kg | 335 /2365 |
| Weight distribution when unloaded,drive side/load side | kg | 1045 /655 |
| Wheel Types | PU | |
| Load Wheel | mm | φ285×100 |
| Drive wheel | mm | φ230×110 |
| Wheel tread,drive side | b10(mm) | / |
| Wheel tread,load side | b11(mm) | 804 |
| Mast tilting | α/β(°) | 2/4 |
| Mast closed height | h1(mm) | 1995 |
| Free lift height | h2(mm) | 110 |
| Lift height | h3(mm) | 3000 |
| Mast extended height | h4(mm) | 3530 |
| Overhead guard height | h6(mm) | 1965 |
| Seat height | h7(mm) | 930 |
| Overall length | L1(mm) | 2330 |
| Length to fork face | L2(mm) | 1410 |
| Overall width | b1/b2(mm) | 912 |
| Fork size | l/e/s(mm) | 920/100/35 |
