Gas Engine Lp Cylind Forklift Nissan K21
Basic Info Model NO.：FG70 Lift height：3000~5000mm Condition：New Certificate：EPA ISO Ce Fork Size：1220mm*150mm*70mm Weight：9750kg Engine：Psi4.3L Rated Power：76/2300 Wheelbase：2250mm Color：Decided by Buyer Max.Lifting Height：3000mm Cylinder：6 Optional：Tire, Mast, Lifting Height Trademark: Noelift...
Send Inquiry
Product Introduction
Basic Info
Model NO.：FG70
Lift height：3000~5000mm
Condition：New
Certificate：EPA ISO Ce
Fork Size：1220mm*150mm*70mm
Weight：9750kg
Engine：Psi4.3L
Rated Power：76/2300
Wheelbase：2250mm
Color：Decided by Buyer
Max.Lifting Height：3000mm
Cylinder：6
Optional：Tire, Mast, Lifting Height
Trademark: Noelift
Transport Package:Container
Specification:3565mm*2010mm*2430mm
Origin:China
HS Code:8427209000
Product Description
6 ton 7 ton LPG/Gasoline dual fuel Forklift with psi engine
The specification of 7 ton LPG/Gasoline dual fuel Forklift with GM Engine
Product Features
1.Safe:
LED work lights and warning lights make it safer and more efficient evenin poor lighting conditions.
New designed overhead guard protective device prevent the sudden accidents.
Thicker reinforcing plate ensure the safety and efficiency.
2.Easy to operate:
Linde-Technology single chain with reinforced load backrest--makes an excellent and wider field of visionfor operator.
3.Beautiful and comfortable:
New suspension adjustable seat makes the long time operating more comfortable.
Step area is 1.5 times larger with lower step height than fellow forklifts.
4.Durable:
Sunken tilt cylinder under the floor build broader flat floor and less abrasion.
Change plastic slider to alloy copper slider, reduce the abrasion and narrow the gap between masts.
Thicker steering axle bridge deck.
5.Environmental:
Middle muffler, more environmental.
6.High technology:
Maintenance free radiators adopt Germany technology.
After sales service
Nowadays we have been sell more than100 countries.
All the products of NOelift supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please see to our website and product's quality certificate.
The specification of 7 ton LPG/Gasoline dual fuel Forklift with GM Engine
| Rated Capacity | kg | 6000 | 7000 | ||
| Load Centre | mm | 600 | 600 | ||
| Lift Height | mm | 3000 | 3000 | ||
| Fork Size | L×W×T | mm | 1220×150×60 | 1220×150×70 | |
| Mast Tilt Angle | F/R | Deg | 6°/12° | 6°/12° | |
| Fork Overhang (Wheel center to fork face) | mm | 590 | 595 | ||
| Ground Clearance(Bottom of mast) | mm | 200 | 200 | ||
| Overall Dimension | Length to face of fork(Without fork) | mm | 3440 | 3565 | |
| Overall Width | mm | 2010 | 2010 | ||
| Mast Lowered Height | mm | 2500 | 2500 | ||
| Mast Extended Height(With backrest) | mm | 4415 | 4415 | ||
| Overhead Guard Height | mm | 2430 | 2430 | ||
| Turning Radius (outside) | mm | 3250 | 3350 | ||
| Speed | Travel (Full load) | km/h | 30 | 30 | |
| Lifting (Full load) | mm/s | 500 | 460 | ||
| Max.Gradeability | % | 20 | 20 | ||
| Tyre | Front | mm | 8.25-15-14PR | 8.25-15-14PR | |
| Rear | mm | 8.25-15-14PR | 8.25-15-14PR | ||
| Wheelbase | mm | 2250 | 2250 | ||
| Self weight | kg | 8750 | 9750 | ||
| Battery | Voltage/Capacity | V/Ah | 12/120 | 12/120 | |
| Engine | Model | PSI4.3L | PSI4.3L | ||
| Manufacture | PSI | PSI | |||
| Rated output/r.p.m. | kw | 76/2300 | 76/2300 | ||
| Rated torque/r.p.m. | N·m | 324/1700 | 324/1700 | ||
| No.of Cylinder | 6 | 6 | |||
| Bore×Stroke | mm | 101.6×88.4 | 101.6×88.4 | ||
| Displacement | cc | 4300 | 4300 | ||
| Fuel Tank Capacity | L | 125 | 125 | ||
| Transmission | Type | Hydraulic | Hydraulic | ||
| Stage | FWD/RVS | 2/2 | 2/2 | ||
Product Features
1.Safe:
LED work lights and warning lights make it safer and more efficient evenin poor lighting conditions.
New designed overhead guard protective device prevent the sudden accidents.
Thicker reinforcing plate ensure the safety and efficiency.
2.Easy to operate:
Linde-Technology single chain with reinforced load backrest--makes an excellent and wider field of visionfor operator.
3.Beautiful and comfortable:
New suspension adjustable seat makes the long time operating more comfortable.
Step area is 1.5 times larger with lower step height than fellow forklifts.
4.Durable:
Sunken tilt cylinder under the floor build broader flat floor and less abrasion.
Change plastic slider to alloy copper slider, reduce the abrasion and narrow the gap between masts.
Thicker steering axle bridge deck.
5.Environmental:
Middle muffler, more environmental.
6.High technology:
Maintenance free radiators adopt Germany technology.
After sales service
Nowadays we have been sell more than100 countries.
All the products of NOelift supplied with one year or 2000 working hours (which occurs first) period quality warranty.
Detail clauses and policies please see to our website and product's quality certificate.
