Diesel Forklift With Bale Clamp
Product Description
Diesel forklift with bale clamp
Main features:
1. A reliable mast
The impact and vibration of mast are reduced significantly by using buffer device. Through finite element analysis plus optimizing the structural parameters, the vibration acceleration is reduced by 40%.
2. More scientific and environmental design
Equipped with high-quality engine, the emission meets the latest European EC and the EPA environmental regulation. The use of Non-asbestos insulation equipment is very effective to lower down the noise.
The innovative design and optimized configuration of the lifting system improve the operator's visibility greatly, and provide a clear and accessible focus of vision to ensure the safety & efficiency of operating.
3. More powerful
Adopt the international electric actuators and makes the truck steering more stable, and output power stronger!
FORKLIFT SPECIFICATIONS
| 1 | NOELIFT | ||||||
| 2 | Model | Unit | FD30/FG(L)30 | FD35/FG(L)35 | FD40/FG(L)40 | FD50 | |
| 3 | Power type | DIESEL | DIESEL | DIESEL | DIESEL | ||
| 4 | Rated capacity | kg | 3000 | 3500 | 4000 | 5000 | |
| 5 | Max lift height | mm | 3000 | 3000 | 3000 | 3000 | |
| 6 | Load centre | mm | 500 | 500 | 500 | 500 | |
| 7 | Mast extend height | mm | 4262 | 4262 | 4275 | 4280 | |
| 8 | Max lift height of fork | mm | 3000 | 3000 | 3000 | 3000 | |
| 9 | Mast closed height | mm | 2065 | 2180 | 2150 | 2330 | |
| 10 | Free lift height | mm | 160 | 170 | 150 | 150 | |
| 12 | Overall length (Without fork) | mm | 2682 | 2693 | 2895 | 3105 | |
| 13 | Overall Width | mm | 1225 | 1225 | 1410 | 1480 | |
| 14 | Front overhang | mm | 479 | 498 | 500 | 565 | |
| 15 | Rear overhang | mm | 495 | 495 | 495 | 540 | |
| 16 | Wheel base | mm | 1700 | 1700 | 1900 | 2000 | |
| 17 | The height of traction pin | mm | 310 | 310 | 330 | 350 | |
| 18 | Min. ground clearance | mm | 135 | 135 | 130 | 160 | |
| 19 | Fork Size | mm | 1070X125X45 | 1070X125X50 | 1070X130X50 | 1070X150X50 | |
| 20 | The distance between forks | mm | 1060/250 | 1060/250 | 1290/260 | 1370/300 | |
| 21 | Tread(front/rear) | mm | 1000/970 | 1000/970 | 1160/1065 | 1180/1190 | |
| 22 | Min. Turning Radius(outside) | mm | 2400 | 2420 | 2700 | 2780 | |
| 23 | Min. Turning Radius(inside) | mm | 200 | 200 | 230 | 270 | |
| 24 | Min. intersecting aisle | mm | 2380 | 2400 | 2685 | 3365 | |
| 26 | Speed | Travel (full load/no load) | km/h | 18/19 | 19/19 | 18/19 | 18/19 |
| 27 | Lifting(full load/no load) | mm/s | 440/480 | 330/370 | 350/380 | 400/450 | |
| 28 | Lowering(full load/no load) | mm/s | 450/500 | 350/400 | 350/400 | 350/400 | |
| 29 | Max.Grade ability(with/without full load) | % | 20/20 | 15/20 | 15/18 | 18/20 | |
| 30 | Total weight | kg | 4270 | 4700 | 5310 | 6400 | |
| 31 | Weight distribution full load(front/rear) | kg | 6543/727 | 7380/820 | 8380/930 | 9540/1360 | |
| 32 | Weight distribution sero load(front/rear) | kg | 1708/2560 | 1880/2820 | 2120/3190 | 2630/3770 | |
FORKLIFT DETAILS
FORKLIFT WITH VARIOUS ATTACHMENTS OPTIONAL
such as paper roll clamp, bale clamp, pull/push clamp, tire clamp so on.
Noelift forklifts under ISO9001:2008 and CE norms.
Certifications
ISO9001-2008 CERTIFICATE & CE CERTIFICATE
Our company
Noelift Forklift factory with years experiences, our forklifts already exported to Austria, Saudi, Arabia, USA, Malaysia, Peru so on.
as one of the professional material handling equipment manufacturer, we provide whole product range including diesel/gasoline/LPG forklift truck with load capacities of 1 to 10tons and electric/warehouse trucks, which including 1-3.5tons electric forklift trucks, 1-2.5tons electric reach trucks, electric stackers, electric pallet trucks, hand-hydraulic pallet trucks, semi-electric stackers, electric tow tractors, etc. The full range encompassess close to 100 different models.
Welcome to get best material handling equipment solutions from NOELIFT!
We are at your services!
1.) Packaging Details: International packing way, packed with thick plastic film.
2.) Delivery Detail: 25days after the advance payment
1 We promise reply in time.
2 Afford partner with 1 year free maintenance.
3 Afford OEM service.
4 Accept the feedback and improve.
any inquiry pls freely contact me!
FAQ
Q1. What is your terms of packing?
A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q2. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and the quantity of your order.
Q5. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q6. How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
Q7. What about after-sales services?
A1: During Warranty, we will offer spare parts needed with free chrage withion one week by international expresses, such as TNT, DHL, UPS and Fedex so on.
2: Technical staff 24hours online supports.
3: Engineer overseas support available.
Q8. How can we contact you more easily?
I can be directly reached at whatsapp.
