Small And Heavy-Duty Rough Terrain Forklifts
Every range includes multiple models, each offering unique features to suit various needs.
The compact options are especially well-suited for operating in tight work environments or restricted spaces.
all terrain forklift Specifications
What is a Rough Terrain Forklift?
A rough terrain forklift is a type of material handling equipment specifically engineered to navigate and function effectively on difficult surfaces like mud, gravel, uneven terrain, or rugged construction sites. Designed for robustness and reliability, this forklift excels in maintaining high performance even in demanding and harsh environments.
Noelift Rough Terrain Forklift Advantages
Noelift's rough terrain forklifts are built to tackle environments that standard forklifts simply can't handle. Their standout features include:
Exceptional Climbing Capability– Effortlessly manage steep inclines and challenging terrains.
Enhanced Ground Clearance – Safeguards the chassis and ensures seamless movement over obstacles.
Robust Powertrain – Provides reliable performance, even under maximum load.
Heavy-Duty Off-Road Tires – Engineered for optimal grip on uneven and rugged surfaces.
Small Rough Terrain Forklift – Compact Yet Powerful
When space is limited-such as in farms, warehouses, or small construction sites-a small rough terrain forklift offers the perfect solution. With a compact design and exceptional maneuverability, it provides all the benefits of a terrain forklift while fitting into tight spaces, making it ideal for versatile lifting and transporting tasks.
Multi-Purpose Handling Capability
From moving heavy loads to loading and unloading containers, from handling timber to dumping construction materials, a rough terrain forklift can do it all.
Compatible attachments include:
- Fork positioners
- Buckets
- Tilting carriages
- Side shifters (integrated or hook-on)
- By switching attachments, one forklift can perform multiple tasks, increasing productivity and reducing equipment costs.


Wide Range of Applications
Terrain forklifts are widely used in:
- Construction – Building sites, infrastructure projects
- Agriculture – Market gardening, farm logistics
- Industrial Operations – Sawmills, automotive recycling, mining
- Public Works & Logistics – Outdoor loading, off-road material handling
Why Choose Noelift Terrain Forklifts?
From small rough terrain forklift models for compact spaces to heavy-duty all-terrain forklifts for the toughest environments, Noelift delivers machines with premium configurations, advanced safety features, and industry-leading reliability. Whatever your terrain, we have the forklift to match your needs.
Specifiction parameters
| MODEL | FD25-S | FD30-S | FD35-S | FD40-S | ||||
| CHARACTERISTICS | POWER | DIESEL | ||||||
| CAPACITY | kg | 2500 | 3000 | 3500 | 4000 | |||
| LOAD CENTER | mm | 500 | 500 | 500 | 500 | |||
| LFT HEIGHT | h | mm | 3000 | 3000 | 3000 | 3000 | ||
| MAST TLT ANGLE | F/R | Deg | 8/12 | 8/12 | 8/12 | 8/12 | ||
| MIN.TURNING | Wa | mm | 2910 | 2910 | 2910 | 2960 | ||
| RADIUS | ||||||||
| MIN.GROUND CLEARANCE | MAST | mm | 250 | 250 | 250 | 250 | ||
| FRAME | mm | 310 | 310 | 310 | 355 | |||
| OVERHEAD | h3 | mm | 2220 | 2220 | 2220 | 2265 | ||
| GUARD HEIGHT | ||||||||
| FRONT LOAD DISTANCE | mm | 450 | 450 | 450 | 490 | |||
| PERFORMANCE | TRAVEL SPEED | LOAD | km/h | 22 | 22 | 22 | 22 | |
| LFT SPEED | LOAD | mm/s | 450 | 440 | 420 | 420 | ||
| MAX. | LOAD | % | 16 | 16 | 16 | 16 | ||
| GRADEABILITY | ||||||||
| DEMENSION | TOTAL LENGTH | WITHOUT | L2 | mm | 2960 | 2960 | 2960 | 3000 |
| FORK | ||||||||
| TOTALWIDTH | b | mm | 1550 | 1550 | 1550 | 1650 | ||
| MAXHEIGHT | h4 | mm | 4350 | 4350 | 4350 | 4350 | ||
| MAST HEIGHT | h1 | mm | 2230 | 2230 | 2230 | 2300 | ||
| CHASSIS | TYRE | FRONT | 12-16.5-14PR | 12-16.5-14PR | 12-16.5-14PR | 14-17.5-16PR | ||
| REAR | 27×10.5-15PR | 27×10.5-15PR | 27×10.5-15PR | 10-16.5-12PR | ||||
| WHEELBASE | L3 | mm | 1850 | 1850 | 1850 | 1850 | ||
| WHEELTREAD | F/R | mm | 1250/1205 | 1250/1205 | 1250/1205 | 1300/1205 | ||
| SERVICE WEIGHT | WITHOUT | Kg | 4650 | 4800 | 4950 | 5200 | ||
| LOAD | ||||||||
| MODEL | FD25-F | FD30-F | FD35-F | FD40-F | ||||
| HARACTEISTICs | POWER | DIESEL | ||||||
| CAPACITY | kg | 2500 | 3000 | 3500 | 4000 | |||
| LOAD CENTER | mm | 500 | 500 | 500 | 500 | |||
| LIFT HEIGHT | h | mm | 3000 | 3000 | 3000 | 3000 | ||
| MIN.TURNING RADIUS | Wa | mm | 3120 | 3120 | 3120 | 3120 | ||
| PERFORMANCE | MAX.TRAVELING SPEED | LOAD | km/h | 20 | 20 | 20 | 20 | |
| MAXLIFTING SPEED | LOAD | mm/s | 530 | 530 | 480 | 480 | ||
| MAX.GRADEABILITY | LOAD | % | 30 | 30 | 30 | 30 | ||
| DEMENSION | WITH FORK | L1+L2 | mm | 4135 | 4135 | 4135 | 4135 | |
| TOTAL LENGTH | ||||||||
| WITHOUT FORK | h1 | mm | 3065 | 3065 | 3065 | 3065 | ||
| TOTALWIDTH | b | mm | 1450 | 1600 | 1600 | 1600 | ||
| MAXHEIGHT | h4 | mm | 4350 | 4350 | 4350 | 4350 | ||
| MAST HEIGHT | h1 | mm | 2235 | 2235 | 2235 | 2280 | ||
| HASSIS | FRONT | 14-17.5-14PR | 14-17.5-14PR | 14-17.5-14PR | 14-17.5-14PR | |||
| TYRE | ||||||||
| REAR | 10.0/75-15.3 | 10.0/75-15.3 | 10.0/75-15.3 | 10.0/75-15.3 | ||||
| WHEELBASE | L3 | mm | 1880 | 1880 | 1880 | 1880 | ||
| SERVICE WEIGHT | WITHOUT | Kg | 5050 | 5250 | 5545 | 5800 | ||
| LOAD | ||||||||
Products Certifications

FAQ
Q1. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q2. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.
Q3. How about your delivery time?
A: Generally, it will take 20 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q4. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q5: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.
Our services
1. One-stop solutions offer
2. OEM services offer
3. 24 hours non stop service offer
4. Track the products for you once every two days, until you get the products.
5. During warrarnty, spare parts delivery within one week for free.
Products Information
NOELIFT EQUIPMENT CO.,LTD, works in forklift industrial for more than 10 years. we have agent in Malaysia and Peru and Canada. if you are looking for long-term cooperation, welcome to grow up together with us!
