Three-Way Electric Stacker For 1.6 Meters Aisle Width
Characteristics:
1. Max. Load capacity is 1000kg, Max. Lifting height is 7500mm
2. Load capacity is 1000kg while lifting height is 6000mm, and 750kg while lifting height reach7500mm
3. The AC motor ensures the stability and easy maintenance.
4. The regenerative braking extends the once recharge operating time.
Certification:
Our factory :
| Specification | ||||
| Manufacturer | - | Noelift | Noelift | |
| Operation type | - | Standing posture | Standing posture | |
| Model | - | TC10-60 | TC15-60 | |
| Power type | - | Full-Electric | Full-Electric | |
| Capacity | kg | 1000 | 1500 | |
| Max lifting height | mm | 6000 | 6000 | |
| Load center | mm | 500 | 500 | |
| Wheel type | - | Pu solid tire | Pu solid tire | |
| Fork dimensions | mm | 1070*100*35 | 1070*125*50 | |
| Fork spread | - | 260-820 | 265-760 | |
| Overall length including fork | mm | 2890 | 3010 | |
| Overall width | mm | 1370 | 1550 | |
| Height-mast Lowered | mm | 3250 | 3125 | |
| Turning radius | mm | 1880 | 2000 | |
| The height of overhead guards | mm | 2325 | 2280 | |
| Min ground clearance | mm | 40 | 40 | |
| Max travel speed | km/h | 7.0/8.0 | 6.8/7.8 | |
| Lifting speed | mm/s | 180/315 | 120/270 | |
| Total weight | kg | 5250 | >5600 | |
| Driving wheel | mm | Φ380×165 | Ø382*142 | |
| front wheel | mm | Φ140×100 | Ø145*100 | |
| Balance wheel | mm | Φ204×76 | Ø180*76 | |
| Battery capacity | V/Ah | 48V /400 AH | 48/400 | |
| Charger-intelligent | V/A | 48V /50 A | 48/50 | |
| Driving motor | kw | 5.5 (AC) | 5.0(AC) | |
| Lifting motor | kw | 7.5 | 7.5(DC) | |
| Transmission controller type | - | Electric | Electric | |
| Walking adjustable type | - | Holzer type accelerator | Holzer type accelerator | |
| Braking type | - | Electromagnetic | Electromagnetic | |
