Function
1. Smart body,with attractive appearance.High-strength frame designed for tough pallet handing tasks.
2.Lower consumption,Lower service cost,while higher performance.Ideal choice replacing manual stacker or semi-electeic stacker. 3.24V/65AH(80AH optional) maintenance free battery contributes to strong power and easier operation,meeting most requirements for light and medium duty applications.
4.Compact structure and reasonable layouts provides steadiness and durability during operation.
5.Intelligent and modulai designs enhance easier operation,convenient dismantle and quick service.
6.Automatic Dormant Function could cut controller's connection to the truck when it has not been in use for 15 minutes.This unique feature prevents wasteful power consumption as well as accidents.
Detailed specification
| Manufacturer | Noelift | ||||
| Model | ES10M | ES10MS | ES15M | ES15MS | |
| Operate Type | Walkie | Walkie | Walkie | Walkie | |
| Capacity | kg | 1000 | 1000 | 1500 | 1500 |
| Load center | mm | 500 | 500 | 500 | 500 |
| Wheelbase | mm | 1208 | 1208 | 1208 | 1208 |
| Service Weight (Incl.Battery) | kg | 460/530/ 560/590 | 460/530/ 560/590 | 510/580/ 610/640 | 707/740/ 775/806 |
| Lift Height | mm | 1600/2500/ 3000/3500 | 1600/2500/ 3000/3500 | 1600/2500/ 3000/3500 | 1600/2500/ 3000/3500 |
| Overall Length | mm | 1716 | 1716 | 1716 | 1716 |
| Overall Width | mm | 800 | 1310/1460/ 1610 | 800 | 1310/1460/ 1610 |
| Fork Size | mm | 1150*160*50 | 1070*100*40 | 1150*160*50 | 1070*100*50 |
| Outside Fork Width | mm | 560 | 220-880 | 560 | 200-800 |
| Drive Motor | kw | 0.75DC | 0.75DC | 1.10DC/1.2AC | 1.10DC/1.2AC |
| Lifting Motor | kw | 2.20DC | 2.20DC | 2.20DC | 2.20DC |
| Battery | V/Ah | 24/80 | 24/80 | 24/100 | 24/100 |
| Controller | Curtis | Curtis | PG | PG | |
| Tyre Type | PU | ||||
| Service Brake | Regenerating | ||||
| Parking Brake | Electromegnetic | ||||
Q1:Are you factory or trade company?
Factory+trade company
We have our own factory with 10 years experiences in trailer production.Also we own modified factory for trucks.Besides trucks and trailers,various international brand earthmoving machines is available.We sincerely welcome you to visit our factory.
Q2: Where is your company?
We are based in SARAWAK, Malaysia, start from 2015,sell to . There are total about 51-100 people in our office.
Q3: Do you supply the spare parts?
Yes, we supply the spare parts.Just send us the list of the accessories which you need.
Q4:What is your delivery time?
A4: It is about 10-15 days after receiving your advance payment in general. The specific delivery time depends on the products and quantity of your order.Sometimes we have some in stock.
Q5: Can youaccept customization?
A5: Yes.We can customize as your requirements, including size, appearance, color, engine etc.,
Q6:Do you test all your goods before delivery?
A6: Yes, we have 100% test before delivery. We have a strict quality and safety management system.
