Self Lift Stacker
Product Description
Self lift stacker, portable forklift, self lift forklift, self loading forklift, self loader
The ultimate multi purpose self lifting stacker combining all the benefits of a Tail Lift, Hand Pallet Truck, Stacker, Ramp and Swing Lift into one product.
The Pallet Lifter with its Self Lifting design allows the machine to load and unload its self from your van or truck.
The pallet lift comes with a maintenance free 12v /45ah battery for stable performance.
NOTED: ONLY Suitable for Standard Open-Bottom (European style) pallets 800x1200mm pallet and 1000x1200mm pallet.
How to works?
Product Specifications
Product name | SELF LIFT STACKER | ||
Brand | NOEIFT | NOEIFT | NOEIFT |
Operation | Manual Driving, Electrical Lifting | ||
Capacity | 500Kg | 500Kg | 500Kg |
Weight | 193Kg | 200Kg | 219Kg |
Lift height | 800mm | 1000mm | 1300mm |
Height in Lowerd Position | 1150mm | 1297mm | 1597mm |
Overall length | 1570mm | 1570mm | 1570mm |
Overall width | 786mm | 786mm | 786mm |
Fork Length | 1150mm | 1150mm | 1150mm |
Material of Wheels | Nylon tire | Nylon tire | Nylon tire |
Steering wheel size | 100x45 | 100x45 | 100x45 |
Loading wheel size | 70x60 | 70x60 | 70x60 |
Middle wheel | 40x25 | 40x25 | 40x25 |
Motor Power Lifting | 0.8kw | 0.8kw | 0.8kw |
Battery | 12/45V/Ah | 12/45V/Ah | 12/45V/Ah |
Charger Battery | inclusive | inclusive | inclusive |
Brake Type | Mechanical | Mechanical | Mechanical |
Max. lift speed(load/unload) | 45/60mm/s | 45/60mm/s | 45/60mm/s |
Max. decend speed(load) | 70mm/s | 70mm/s | 70mm/s |
Pacakge way | strict pacakge, packed with thick plastic film+cardboard+wooden pallet. | ||
Company Information
NOELIFT EQUIPMENT CO.,LTD, works in forklift industrial for more than 10 years. we have agent in Malaysia and Peru and Canada. if you are looking for long-term cooperation, welcome to grow up together with us!
