1.5t 3-Way Electric Pallet Stacker

Main Features:
1. 3-way pallet stacker forks can rotate 180°and do left-right side shift without body turning, with high strength mast design. Min. net channel: 1500mm; Max. lifting height: 9000m. The 3-way pallet stacker can improve space utlization and increase the storage capacity. 2.Advanced Curtis controller and more stable, safer whole-AC system for high efficency, energy conservation and environmental protection. 3.Maintenance-free whole-AC driving system for quick and accurate reaction. Maintenance-free motor, with long service life and low noise and low maintenance cost.
4.Standard electric power steering is safe and reliable, with easy and comfortable operation.
5.Large section mast structure design to ensure the rigidity of mast and improve loading performances, which is very suitable to high shelf storage.
6.Imported hydraulic parts for stable and reliable hydraulic system. 7.Side pull type battery for convenient charging and maintenance.

3-Way Electric Pallet Stacker

TC Series 1.0-1.5T 3-way pallet stacker (Stand-on Driving type)

3-way stacking function: forks can rotate 180° and do left-right side shift without body turning.

The 3-way pallet stacker is the first choice of intensive storage, which is mainly used in logistics, medicine, food, and low-temperature cold storage.

● Stacking in ultra-narrow roadways and high shelf design;

● Horizontal handling;

● Load/unload cargos.

Manufacturer		NOELIFT	NOELIFT	NOELIFT	NOELIFT
Model		TC10	TC10SQ	TC15	TC15SQ
Power type		Battery	Battery	Battery	Battery
Operation Type		Stand-on	Stand-on	Stand-on	Stand-on
Service weight(incl. battery)	kg	4260	4800	4690	5520
Rated capacity	Q(kg)	1000	1000	1500	1500
Load center	C(mm)	500	500	600	600
Lift height	h3(mm)	3000	4500	3000	4500
Fork dimension	l/e/s(mm)	1000/125/50	1000/125/50	1200/125/50	1200/125/50
Front overhang	x(mm)	657	657	670	670
Turning radius	Wa(mm)	1880	1880	1980	1980
Max. climbing ability		/	/	/	/
Travelling speed ,laden/unladen	km/h	7.5/8	7.5/8	7.5/8	7.5/8
Lifting speed ,laden/unladen	mm/s	230/300	230/300	200/300	200/300
Lowering speed,laden/unladen	mm/s	310/310	310/310	340/340	340/340

Q1. What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages
before you pay the balance.
Q2. What is your terms of delivery?
A: EXW, FOB, CFR, CIF.
Q3. How about your delivery time?
A: Generally, it will take 20 days after receiving your advance payment. The specific delivery time depends
on the items and the quantity of your order.
Q4. Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q5: How do you make our business long-term and good relationship?
A:1. We keep good quality and competitive price to ensure our customers benefit ;
2. We respect every customer as our friend and we sincerely do business and make friends with them,
no matter where they come from.

1. One-stop solutions offer

2. OEM services offer

3. 24 hours non stop service offer

4. Track the products for you once every two days, until you get the products.

5. During warrarnty, spare parts delivery within one week for free.

NOELIFT EQUIPMENT CO.,LTD, works in forklift industrial for more than 10 years. we have agent in Malaysia and Peru and Canada. if you are looking for long-term cooperation, welcome to grow up together with us!
