Manual Stacker SYC Series Pallet Jack For Sale
Product Detail
| Specifications | |||||||||
| Standard | |||||||||
| 1.1 | Manufacturer | NOELIFT | NOELIFT | NOELIFT | NOELIFT | NOELIFT | NOELIFT | NOELIFT | |
| 1.2 | Model | SYC0516 | SYC1016 | SYC1516 | SYC2016 | SYC1020/1520/2020 | SYC1025/1525 | SYC1030/1530 | |
| 1.3 | Power type | Manual | Manual | Manual | Manual | Manual | Manual | Manual | |
| 1.4 | Rated load | kg | 500 | 1000 | 1500 | 2000 | 1000/1500/2000 | 1000/1500 | 1000/1500 |
| 1.5 | Load center | mm | 500 | 500 | 500 | 500 | 500 | 500 | 500 |
| 2.1 | Service Weight | kg | 150 | 224 | 240 | 270 | 290 | 310 | 330 |
| 3.1 | Load wheel size | mm | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 | Φ180*50 |
| 3.2 | Front wheel size | mm | Φ80*58 | Φ80*58 | Φ80*58 | Φ80*58 | Φ80*58 | Φ80*58 | Φ80*58 |
| 3.3 | Number of wheels,front/rear | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | |
| 4.1 | Max. Lift height | mm | 1600 | 1600 | 1600 | 1600 | 2000 | 2500 | 3000 |
| 4.2 | Minimum height of fork surface | mm | 85 | 85 | 85 | 85 | 85 | 85 | 85 |
| 4.3 | Overall dimension | mm | 1600*760*2030 | 1600*760*2030 | 1600*760*2030 | 1600*760*2030 | 1600*760*1580 | 1600*760*1840 | 1600*760*2080 |
| 4.4 | Fork Length | mm | 1000 | 1150 | 1150 | 1150 | 1150 | 1150 | 1150 |
| 4.5 | Fork width | mm | 330-740 | 330-740/550 | 330-740/550 | 330-740/550 | 330-740 | 330-740 | 330-740 |
| 4.6 | Leg width | mm | 690 | 690 | 690 | 690 | 690 | 690 | 690 |
| 5.1 | Mast type | Single type | Single type | Single type | Single type | Duplex mast | Duplex mast | Duplex mast | |
PRODUCT ADVANTAGE
1.It applies C type steel structure design , Lifting more stable and safe.
2.AIll Manual stacker have been equipped with wheel frame protection device.
3.The handle have been surround with rubber.With lengthening design,Using more comfortable.
4.Single Frame have two ways to unload by manual and pedal,using more flexible.
5.Fork with adjustable nut ,it can easy to adjust the fork height.
6.Wheel frame equipped with grease ftting design,It will help do routine maintenance for bearing.
7.There are too many kinds of Fork types,Fixed Fork, Adjusting fork,also with the adjusting wide leg or Fixed wide leg.
CE，ISO Certificates
Our Company
Package
Take the customer required in consideration, we realize that better price should be together with best service. So we will promise to offer good quality product with lower price and offer 7X24 hours on-line service to you. Let's join hand together, you will find the one you want. Any agent or distributor is highly appreciated.
Hot Tags: manual stacker syc series pallet jack for sale, China manual stacker syc series pallet jack for sale manufacturers
