Bale Clamp Electric Forklift
4.8meters triplex mast Electric Forklift with bale clamp Forklift power: electric, electricity Mast type: duplex mast, full free duplex mast, full free triplex mast.
Optional lift height range: 3 - 6 meters.
Optional load capacity range: 1500kg - 5000kg.
production Description for bale clamp electric forklift
Our Electric forklift optional load capacity is 1.5-5tons. optional lift height is 3-6meters.
Bale Clamps can handle almost all types of baled products, including cotton, synthetic textile fibres, wool, flax, ranges, hay and recycled clothing.
Bale clamp features:
- High stability - solid design
- View-optimised design
- Solid and thin arm construction in different versions
- Quick and simple assembly
Valveblock sideshift or independent sideshift serially
- SOFTSTOP end-of-stroke slow down and SMOOTHROLL bottom hooks with compact rollers serially with independent sideshift
- Highly wear-resistant sliding profiles fitted between the profiles for improved sliding properties
Optionally available: cylinder and piston rod protection
Bale clamp possible operational areas:
Palletless transportation of bales of paper, waste paper, tobacco, textiles, boxes and other containers.
Specially designed clamping arms are available for transportation of pulp, foamed plastic (polystyrene), wool and Big-Bags
Recycling industry, paper industry, textile industry
Important parameters
|
Standard |
|||||||
|
1.1 |
Brand |
NOELIFT |
|||||
|
1.2 |
Model |
TK15 |
TK20 |
TK25 |
TK30 |
TK35 |
|
|
1.3 |
Power type |
Battery |
Battery |
Battery |
Battery |
Battery |
|
|
1.4 |
Operation type |
Seat |
Seat |
Seat |
Seat |
Seat |
|
|
1.5 |
Loading capacity |
Q(kg) |
1500 |
2000 |
2500 |
3000 |
3500 |
|
1.6 |
Loading center |
C(mm) |
500 |
500 |
500 |
500 |
500 |
|
Tire、 Rim |
|||||||
|
2.1 |
Tire type front/rear |
Pneumatic |
Solid/Solid |
||||
|
2.2 |
Front tire |
6.50-10-10PR |
7.00-12-12PR |
7.00-12-12PR |
28×9-15-12PR |
28×9-15 |
|
|
2.3 |
Front wheel rim |
5.00F-10 |
5.00S-12 |
5.00S-12 |
7.00T-15 |
7.00T-15 |
|
|
2.4 |
Rear tire |
5.00-8-10PR |
18×7-8-14PR |
18×7-8-14PR |
18×7-8-14PR |
18×7-8 |
|
|
2.5 |
Rear wheel rim |
3.50D-8 |
4.33R-8 |
4.33R-8 |
4.33R-8 |
4.33R-8 |
|
|
2.6 |
Tire quantity front/driving/rear(X=driving) |
2X / 2 |
2X / 2 |
2X / 2 |
2X / 2 |
2X / 2 |
|
Products Certifications
Noelift attend exhibition at dubai
Noelift, one of the forklift manufacturers, recently attended the Dubai exhibition to showcase our latest models and innovations in the industry. The event was a huge success with attendees from all over the world showing interest in their products.
The company exhibited a wide range of forklifts including electric, diesel and propane forklifts. Customers were impressed with the exceptional quality of the machines, their robust design, outstanding performance, and safety features.
The event was a great opportunity for Noelift to meet with customers and dealers, and to understand the ever-changing needs of the market. The company's team was delighted to see the positive feedback, and to hear about the accomplishments of their clients who use their forklifts.
Company Information
NOELIFT EQUIPMENT CO.,LTD, works in forklift industrial for more than 10 years. we have agent in Malaysia and Peru and Canada. if you are looking for long-term cooperation, welcome to grow up together with us!
