10T Forklift
10ton diesel forklift truck FD100
1, Seat on type opertaion.
2, Engine option: ISUZU 6BG1, CUMMINS , CY6102, XICHAI 6110, PEKINS,
3, 3-6M lifting height, duplex/triplex/container mast.
4, Different lengths forks and solid tyres is optional
5, Wide vision mast, soft and comfortable design.
6, Automatic hydraulic transmission.
7. with fork positioner and side shift.
Product Picture


Specifications of 8-12 tons forklift | |||||
Manufacture | |||||
Model | Unit | FD80 | FD100 | FD120 | |
Power type | DIESEL | DIESEL | DIESEL | ||
Rated capacity | kg | 8000 | 10000 | 12000 | |
Max lift height | mm | 3000 | 3000 | 3000 | |
Load centre | mm | ||||
Mast extend height | mm | 4380 | 4320 | 4350 | |
Max lift height of fork | mm | 3000 | 3000 | 3000 | |
Mast closed height | mm | 2500 | 2840 | 2870 | |
Free lift height | mm | 205 | 100 | 180 | |
Distance from seat to overhead guard | mm | 1080 | 1020 | ||
Overall length (Without fork) | mm | 3600 | 4270 | 2430 | |
Overall Width | mm | 1995 | 2165 | 4820 | |
Front overhang | mm | 590 | 720 | 720 | |
Rear overhang | mm | 760 | 742 | 900 | |
Wheel base | mm | 2250 | 2800 | 3200 | |
The height of traction pin | mm | 395 | 520 | 520 | |
Min. ground clearance | mm | 200 | 225 | 240 | |
Fork Size | mm | 1220X150X75 | 1220X175X80 | 1220X175X80 | |
The distance between forks | mm | 1840/300 | 2460/450 | 2460/450 | |
Tread(front/rear) | mm | 1470/1700 | 1600/1800 | 1600/1700 | |
Min. Turning Radius(outside) | mm | 3370 | 4080 | 4720 | |
Mast tilt angle | deg | ||||
Total weight | kg | 9850 | 12860 | 13520 | |
Tire | Quantity | ||||
Type | |||||
Transmission Type | Automatic | ||||


Packaging & Shipping
heavy duty forklift's mast should be dismantled when loaded into container because of its overall height is higher than contianer.
